EJ39 Magnetic Incremental Encoder

EJ39 Magnetic Incremental Encoder

  • Series:EJ
  • Format:See the following profile
  • Specifications

    Model: EJ39 series
    Name:

    EJ39 Magnetic Incremental Encoder

    Main Specifications:

    Rated power: DC 5 Vcc, 10 mA;

    Number of detent: 18

    Pulses: 9 Pulses

    Lateral switch: 4 directions

    Push switch travel: 1.5mm

    Working temperature: -40 ° C ~ 85 ° C

    Rotational life: 100,000 cycles Min;

    Features:

    Magnetic encoder with reliable output, strong anti- interference

    ability and long operating life.

    Compact design with a rotary encoder, 4- direction lateral switches

    and a central push switch in one single part.

    Applications:

    Automotive electronics, household appliances, smart home devices

    and other related electronic devices; It mainly plays the role of

    function selection, menu page turning, volume adjustment and so on.

    EJ39 Product Specifications

    ONE、MECHANICAL CHARACTERISTIC
    Rotary Encoder
    1. Rotational torque: 40± 10mN.m
    2. Total ratation angle: 360°
    3. Number of detent: 18
    4. Rotational life: 100,000 cycles
    Four-Direction Lateral Push Switch
    1. Lateral push force: 5.0±1.5N

    2. Lateral push travel: 3.5°±1°
    Central Push Switch
    1. Push switch travel: 1.5±0.3mm

    TWO、ELECTRIC CHARACTERISTIC
    1. Rated power: DC 5 Vcc, 10mA;
    2. Insulation resistance: 100MΩ
    3. Dielectric voltage: 1 Minute at AC 300V
    4. Encoder resolution: 9 pulses/360°
    5. Contact resistance of the push & lateral switch: 200mΩ Max

    Note: In this catalog, if some parameters or drawings are different from the "Approval sheet", it's subject to the "Approval sheet".

    Download the EJ four-way switch encoder.pdf

    4-way switch encoder specification
